20W 4''

20W 4'' Commercial Mini Satellite Speaker with Power Tap

DSP129
  • Type: Commercial PA system wall-mounted speaker.
  • Rated power: 20W - compatible with 100V constant voltage and 16Ω low impedance.
  • Power taps: Selectable power taps available based on user requirements.
  • Driver: 4" coaxial driver unit.
  • Installation: Quick and easy mounting with brackets.
  • Design: Compact, neat appearance with extraordinary sound quality.
  • Applications: Ideal for public address systems in offices, hotels, bars, and shopping malls.
Overview Specifications Brochure Related Products Solutions Latest News & Cases

The DSP129 is a 20W 4-inch commercial mini satellite speaker designed for distributed background music and installed audio applications. Its compact satellite form factor provides a practical balance between speaker size, output and discreet installation, making it suitable for commercial interiors where consistent audio coverage is required.

With a power tap for flexible system configuration, the DSP129 is suitable for hospitality, retail, restaurants, cafés and other commercial spaces requiring compact distributed audio.



Model

DSP129

Woofer

4" paper cone

Frequency Response (±3dB)

120Hz-20kHz

RMS Power

20W

Sensitivity

84dB±2dB

MAX. SPL. (1m)

97dB±2dB

Constant Voltage

100V: 10W/20W

Nominal Impedance

16Ω

Attachment

Bracket / Screw

Product Dimensions

148×127×138 mm

Housing Material

ABS

Net Weight

1.23kg




Related Commercial Wall Mount Speaker
